SilverStone RM53-502 5U Rackmount Server Chassis Supports SSI-EEB ATX 360mm Radiator Dual PSU-With Rail

Name: SilverStone RM53-502 5U Rackmount Server Chassis Supports SSI-EEB ATX 360mm Radiator Dual PSU-With Rail
SKU: RM53-502
Price: 54999.00 INR
Availability: InStock

Silverstone

💡 Quick Note on Pricing: Due to daily market fluctuations, GPU and RAM prices update frequently. Please verify today’s live price and stock availability with our team before placing your order

Original price was: ₹86,500.00.Current price is: ₹54,999.00. (Inclusive of GST)

Add to wishlist

Compare

SKU: RM53-502 Categories: Cabinet (Case), SILVERSTONE CABINET Tags: RM53-502, Server Cabinet, server chassis, Silverstone

Fast Shipping

100% Genuine Product

Whatsapp Support

Brand Warranty

Description

SilverStone RM53-502 5U Rackmount Server Chassis Supports SSI-EEB ATX 360mm Radiator Dual PSU-With Rail

Enterprise‑Grade 5U Rackmount Design: Supports 5U rackmount and tower orientation, ideal for servers, NAS systems, and high‑performance workstations.
Advanced Cooling & 360mm Radiator Support: Compatible with up to 360mm front liquid cooling radiators and multiple fan placements for superior thermal performance.
Wide Motherboard Compatibility: Supports SSI‑EEB, SSI‑CEB, Extended ATX, ATX, Micro‑ATX, and Mini‑ITX motherboards for maximum build flexibility.
Dual Power Supply Support: Supports PS2 (ATX), Mini‑Redundant, 2U CRPS Redundant power supplies with optional secondary SFX PSU mounting.
Flexible Storage Configuration: Universal drive cage supports 5.25‑inch, 3.5‑inch, and 2.5‑inch drives for scalable storage requirements.
Secure & Service‑Friendly Build: Front lockable door, chassis intrusion switch, 8 PCI expansion slots, and tool‑less access for enterprise deployments.
The SilverStone RM53‑502 is a professional‑grade 5U rackmount server chassis engineered for data centers, workstations, and NAS environments. It supports SSI‑EEB and ATX motherboards, advanced liquid cooling up to 360mm, and dual power supply configurations. With flexible storage options, high GPU clearance, and superior airflow design, RM53‑502 delivers reliability, scalability, and thermal efficiency for demanding enterprise workloads.

Specification	Details
Model No.	SST-RM53-502
Chassis Form Factor	5U
Motherboard Support	SSI-EEB, SSI-CEB, Extended ATX, ATX, Micro-ATX, Mini-ITX
Material	Steel
External Drive Support	5.25″ x 2 (compatible with 2.5″ x 4 or 3.5″ x 2)
Internal Drive Support	• 3.5″ x 1 (compatible with 2.5″ x 2) • 3.5″ x 2 (compatible with SFX PSU x 1) • 2.5″ x 5 (two expansion cards occupy the 8th slot position)
Cooling System – Front	120mm x 3, 80mm x 3 (2 x 80mm fans included)
Cooling System – Rear I/O	120mm x 1 or 140mm x 1 (1 x 140mm fan included)
Cooling System – Rear Fan Cage	80mm x 2
Radiator Support – Front	120mm / 240mm / 360mm
Radiator Support – Rear	120mm
CPU Cooler Height Clearance	Single CPU: 178mm \| Dual CPU: 101–178mm
Expansion Slots	8
Expansion Card Clearance	• Length: 454mm (without front fans or radiators) • Width: 160mm (with GPU holder), 185mm (without GPU holder)
Power Supply Support	• Primary: PS2 (ATX), Mini Redundant, 2U CRPS Redundant • Secondary: SFX (occupies 3.5″ bracket)
PSU Length Limitation	• Primary: 190mm (unlimited if 3.5″ cage removed) • Secondary: 130mm
Front I/O Ports	USB Type-C x 1, USB 3.0 x 2
LED Indicators	Power Status x 1, HDD Activity x 1, LAN Activity x 2
Dimensions (Incl. Rear Fan Cage)	440mm (W) x 220mm (H) x 530mm (D), 51.3 Liters
Dimensions (Excl. Rear Fan Cage)	440mm (W) x 220mm (H) x 485mm (D), 46.95 Liters
Net Weight	11.47 kg
